SWISSIWS SULFATE MGO BOARD
This panel is the most cost-effective fire rated replacement for poured concrete in floors and roof decks as well as walls where high impact fire rated surfaces are required. It allows rapid installation for accelerated schedules while giving architects and contractors a sustainable product that is silica free and mold intolerant.
It is very green in comparison to competitive products. While cement based products use tremendous amounts of energy in their manufacture, SWISSIWS MGO BOARD uses a room temperature process that uses a small fraction of energy in comparison. With no silica, it does not pose the same threat to workers when cutting or sanding. Its mold resistance is exemplary.
Product Details
Dimension of SWISSIWS SULFATE MGO BOARD
| Sizes | 1220*2440, 1200*2400, 1200*2250, 1200*2280, 1100*2750, 1100*2950, 1100*3000 |
| Thickness | 3 mm to 20 mm |
| Fiber cloth | 4*4, 5*5, 6*4, 6*6 |
| Thickness tolerance | 0.5 mm |
| Size tolerance | ±2 mm |
The chart below states the calculated Thermal Resistance (R-value) and Thermal Transmittance (U-value) of the standard thickness SWISSIWS SULFATE MGO BOARD based on test by SGS-CSTC Standards 2018.
| Board Thickness (mm) | U-value (W/m²K) | R-value (m²K/W) |
| 3 | 50.67 | 0.023 |
| 6 | 25.35 | 0.038 |
| 10 | 15.23 | 0.065 |
| 20 | 7.55 | 0.135 |
